RIG SOLUTIONS
MUD PUMPS
We supply complete range of Mud Pump and parts including high chrome sleeve liners, zirconia ceramic liners, urethane bonded pistons with long service life, high temperature and plate type design valves and seat available in API 4 thru 8 size to fit all major mud pumps, a complete line of urethane bonded pistons, replaceable rubber pistons, rubber bonded pistons, a full range of full open 3 web, 4 web interchangeable fluid end modules and accessories, for various OEM's mud pump such as National, Emsco, Gardner Denver, Bomco, Ideco and Oilwell etc.
Triplex Gear End Replacement Parts
Triplex Fluid End Replacement Parts
Triplex Piston Rods
Piston Rod Clamps
Crosshead Extension Rods
Suction Line Dampeners
Liner Wear Plates
Suction/Discharge Manifolds & Strainers
Pulsation Dampeners
Fluid End Modules
TOP DRIVE
Hydraulic Top Drives/Electric Top Drive Ranges from 250 to 1000 Tons
The use of a Top Drive system provides the operator substantial benefits over traditional Kelly Drilling.
Varco TDS 11SA 500 Ton
Varco TDS-8SA - 800 Tons
Varco TDS 1000 - 1000 Ton
DrillMec
Canrig 1275AC-681
Canrig 1050E712
Bentec TD-500-HT
SWIVEL & Overhauling Parts
Direct drive Power Swivel 85 Ton 100 ton & 120 Ton capacity
The single direct drive hydraulic motor eliminates the need for gears, providing improved efficiency, smoother operation and greater dependability. The VTS100 is equipped with a heavy duty floating washpipe assembly rated for 10,000 PSI and incorporates newly designed seals to increase the life expectancy of the washpipe assembly. The VTS100 is equivalent in size to the PS85, but incorporates the torque output of the PS120.
SWIVEL & Overhauling Parts
NOV - Power Swivel - S- 85
NOV - Power Swivel - S-150
NOV - Power Swivel - S-250
Venturetech - XK - 100
Venturetech - XK - 150
TRAVELLING BLOCK
"Traveling Blocks to meet your specific drilling requirements - Sufficient weighting ensures fast free fall - Compact and streamlined design eliminates interference with mast or derrick components.
Long service life is achieved through quality fabrication and careful selection of components."
• Heavy duty, high grade structural steel
• Flame hardened grooves
• High quality tapered roller bearings for sheaves
• Shaft with individual grease passage to each roller bearing
• Traveling Block manufactured according to API 8C
• Climate range: -45°C to +55°C
• Suitable for artic & desert environment
• Suitable for onshore or offshore rigs
• CE conformity
• ATEX conformity on request
BLOWOUT PREVENTER
. Bore: 7.06”to 26.75”(179 mm to 680 mm).
. Pressure rating: 2,000 psi to 15,000 psi(13.8 mpa to 103.5 mpa).
. Minimum operating pressure: 1,500 psi (10.3mpa).
. Maximum operating pressure: 3,000 psi (20.7mpa).
. Operating ports: 1”npt.
. Temperature rating: up to t-75 (-75 °f to 250 °f) (-59 °c to 121 °c).
. Designed and manufactured to iso 13533 (api 16a) for drill through equipment.
IRON ROUGHNECK
NOV 1320 UE , 2000 HP
NOV 1625 UBDE 3000HP
NOV ADS-10T, 3000 HP
FR120 & FR120-C
Floorhand FH-100
Floorhand FH-80
Floorhand FH-100
Torque: Make-up 100,000 ft lb
Torque: Break-out 120,000 ft lb
Single-stroke makeup and breakout improves rig efficiency.
Accurate torque application reduces potential for downhole makeup.
Fewer components aid in troubleshooting and repair.
Three-jaw gripping drastically improves die life.
API 7K-compliant design ensures reduced total cost of ownership.
SHALE SHAKER & SCREENS
• Fluid centering technology increases capacity
• Increased efficiency in a smaller footprint
• Compression fit bed material requires no hardware
• Eliminates bypass of solids under screen panel
• Air actuation offers quick, easy screen changes
• Fail-safe spring system securely retains panels upon loss of air pressure
• All stainless steel pneumatic fittings
• Snap-on protective covers
WELLHEADS
Conventional Wellhead
Working Pressure up to 20,000 Psi (138 MPa)
Temperature up to 450° F (232° C)
Dual completion
Elastomeric sealing
Full metal-to-metal seal completion for severe and harsh environment
ESP well completion
Compact Wellhead
Working Pressures of up to 15,000 Psi (103,5 MPa)
Fluid and gas-tight sealings
Complete range of material class, temperature rating, and PSL requirements of API 6A
Premium elastomer materials that are capable to withstand Rapid Gas Decompression (RGD) as per NORSOK M-710
Running and retrieval tools designed to meet API 6A Annex L requirement
Emergency equipment that includes a full range of slip-type hangers and packoff assemblies
Quick make-up connections (MBQ connectors) that are compatible with API 16A Hub
